• SF5777 is a high performance, 2nd Generation Quasi-Resonant (QR-||TM) PWM controller for offline flyback power converter applications. The built-in proprietary QR-||TM technology with high level protection features improves the SMPS reliability and performance. qyk嘉泰姆




• In SF5777, the "Digital Anti-Jitter' function can automatically select and lock a valley at a given loading, which can achieve audio noise free operation. On the other hand, the "Digital Frequency Jittering" function makes the system have superior EMI performance than conventional QR system. qyk嘉泰姆




• SF5777 is a multi mode controller. When full loadings, the IC works in CCM mode or QR mode based on the AC line input . When the loading goes low, the IC enters into "Digital Frequency Foldback" mode to boost power conversion efficiency. When the output power is very small, the IC enters into burst mode and can achieve less than 100mW no load power. qyk嘉泰姆




• SF5777 integrates functions and protections of Under Voltage Lockout (UVLO), VCC Over Voltage Protection (OVP), Output Over Voltage Protection (Output OVP), cycle-by-cycle Current Limiting (OCP), pins Floating Protection, Over load Protection (OLP), Soft Start , VCC Clamping, Gate Clamping, In SF5777, the protection functions are auto-recovery mode protection. qyk嘉泰姆




•  SF5777 is available in DIP8 packages.qyk嘉泰姆
