By driving an external MOSFET, CXSD62587 is able to significantly improve the efficiency comparing with the conventional Diode rectifier. When CXSD62587 senses Vds of MOSFET less than -300mV, it turns

   产品概述 返回TOPSII嘉泰姆

     CXSD62587 is a synchronous rectifier controller, used for the secondary side rectification of isolation topologies, such as Flyback, Forward, Half Bridge, Full Bridge and LLC converter. By driving an external MOSFET, CXSD62587 is able to significantly improve the efficiency comparing with the conventional Diode rectifier. When CXSD62587 senses Vds of MOSFET less than -300mV, it turns on the MOSFET. Once the Vds is greater than -10mV, CXSD62587 turns off the MOSFET. CXSD62587 supports multiple operation modes, such as DCM, CrCM, CCM and Quasi-Resonant. By implementing the Joulwatt proprietary technology, CXSD62587is able to handle CCM operation.

   产品特点 返回TOPSII嘉泰姆

Supports DCM, Quasi-Resonant, CrCM and CCM operation SII嘉泰姆

Support the isolation topologies, such as Flyback, Forward, Half Bridge and Full Bridge converter SII嘉泰姆

Supports High-side and Low-side Rectification SII嘉泰姆

Output voltage directly supply VCC SII嘉泰姆

Low quiescent current SII嘉泰姆

Under-voltage protection SII嘉泰姆

Fast driver capability for CCM operation SII嘉泰姆

SOT23-6 packageSII嘉泰姆

   应用范围 返回TOPSII嘉泰姆

Flyback and LLC converters SII嘉泰姆

Adaptor SII嘉泰姆

LCD and PDP TVSII嘉泰姆

   技术规格书（产品PDF) 返回TOP SII嘉泰姆

     需要详细的PDF规格书请扫一扫微信联系我们，还可以获得免费样品以及技术支持</span>！</span>
