EPROM/ROM-Based 8-Bit Microcontroller CX8PE51 CX8PE51E Only 47 single word instructions

   产品概述 返回TOPt2G嘉泰姆

The CX8PE51 CX8PE51E series is a family of low-cost, high speed, high noise immunity, EPROM/ROM-based 8-bit CMOS microcontrollers. It employs a RISC architecture with only 47 instructions. All instructions are single cycle except for program branches which take two cycles. The easy to use and easy to remember instruction set reduces development time significantly. The CX8PE51E series consists of Power-on Reset (POR), Brown-out Reset (BOR), Power-up Reset Timer (PWRT), Oscillator Start-up Timer(OST), Watchdog Timer, EPROM/ROM, SRAM, tri-state I/O port, I/O pull-high/open-drain control, Power saving SLEEP mode, 4 real time programmable clock/counter, Interrupt, SPI, RFC, data compare, Wake-up from SLEEP mode, and Code Protection for EPROM products. There are three oscillator configurations to choose from, including the power-saving LP (Low Power) oscillator and cost saving RC oscillator. The CX8PE51E series address 4K×13 of program memory. The CX8PE51E series can directly or indirectly address its register files and data memory. All special function registers including the program counter are mapped in the data memory.

   产品特点 返回TOPt2G嘉泰姆

  ‧ Only 47 single word instructions t2G嘉泰姆

‧ All instructions are single cycle except for program branches which are two-cycle t2G嘉泰姆

‧ 13-bit wide instructions t2G嘉泰姆

‧ 8-bit wide data path t2G嘉泰姆

‧ 5-level deep hardware stack t2G嘉泰姆

‧ 4K x 13 bits on chip EPROM/ROM t2G嘉泰姆

‧ 140 x 8 bits on chip general purpose registers (SRAM) t2G嘉泰姆

‧ Operating speed: DC-20 MHz clock input DC-100 ns instruction cyclet2G嘉泰姆

‧ Direct, indirect addressing modes for data accessing t2G嘉泰姆

‧ One 8-bit real time clock/counter (Timer0) with 8-bit programmable prescalert2G嘉泰姆

 ‧ Three 8-bit real time clock/counter (Timer1, Timer2, and Timer3) with period setting t2G嘉泰姆

‧ Internal Power-on Reset (POR) t2G嘉泰姆

‧ Built-in Low Voltage Detector (LVD) for Brown-out Reset (BOR) t2G嘉泰姆

‧ Power-up Reset Timer (PWRT) and Oscillator Start-up Timer(OST)t2G嘉泰姆

‧ On chip Watchdog Timer (WDT) with internal oscillator for reliable operation and soft-ware watch-dog enable/disable control t2G嘉泰姆

‧ Five I/O ports (38 I/O pins) with independent direction control t2G嘉泰姆

‧ 32 programmable pull-high input pins t2G嘉泰姆

‧ 12 wake-up pins t2G嘉泰姆

‧ 2 open-drain pins t2G嘉泰姆

‧ 2 R-option pins t2G嘉泰姆

‧ Clock output with high driving ability t2G嘉泰姆

‧ 19 channels of 15-bit resolution Resistor to Frequency Converter (RFC) output t2G嘉泰姆

‧ 2 channels of maximum 10-bit resolution Pulse Width Modulation (PWM) output t2G嘉泰姆

‧ Built-in 8-bit data comparator t2G嘉泰姆

‧ Seven internal interrupt source: Timer0 overflow, Timer1 match, Timer2 match, Timer3 match, SPI module (Receive & Transmit), RFC module; One external interrupt source: INT pin change t2G嘉泰姆

‧ Wake-up from SLEEP by port input change t2G嘉泰姆

‧ Power saving SLEEP mode t2G嘉泰姆

‧ Programmable Code Protection t2G嘉泰姆

‧ Built-in RC oscillator with external resistor t2G嘉泰姆

‧ Selectable oscillator options: t2G嘉泰姆

- ERC: External Resistor/Capacitor Oscillator t2G嘉泰姆

- ERIC: External Resistor/Internal Capacitor Oscillator t2G嘉泰姆

- HF: High Frequency Crystal/Resonator Oscillator t2G嘉泰姆

- XT: Crystal/Resonator Oscillator t2G嘉泰姆

- LF: Low Frequency Crystal Oscillator t2G嘉泰姆

‧ Wide-operating voltage range: t2G嘉泰姆

- EPROM : 2.3V to 5.5V t2G嘉泰姆

- ROM : 2.3V to 5.5Vt2G嘉泰姆
