QC2.0 Interface Module CXLB7408 is designed to support QuickCharge QC 2.0 (QC2.0) specifications. It is a low-cost solution to support QC2.0 functions. CXLB7408 incorporates all necessary functions

   产品概述 返回TOPnAZ嘉泰姆

    CXLB7408 is designed to support QuickCharge QC 2.0 (QC2.0) specifications. It is a low-cost solution to support QC2.0 functions. CXLB7408 incorporates all necessary functions to add QC2.0 capability to standard Adaptor designs, Portable Battery designs, and Car-charger designs.

   CXLB7408 supports the full output voltage range of either Class A or Class B. Optionally Class B can be inhibited for protecting the battery charger from accidental damage.

   CXLB7408 automatically detects whether a co nnected Powered Device (PD) is QC2.0 capable before enabling output voltage adjustment. If a PD that is not compliant to QC2.0 is detected the CXLB7408 disables output voltage adjustment to ensure safe operation with legacy 5 V only USB PDs.

   产品特点 返回TOPnAZ嘉泰姆

 Fully supports Quick Charge 2.0 specification nAZ嘉泰姆

 Class A: 5 V, 9 V, and 12 V output voltage nAZ嘉泰姆

 Class B: 5 V , 9 V , 12 V , and 20 V output voltage nAZ嘉泰姆

 USB battery charging specification revision 1.2 compatible nAZ嘉泰姆

 Automatic USB DCP shorting D+ to D- line nAZ嘉泰姆

 Default 5 V mode operation nAZ嘉泰姆

 Very low power consumption nAZ嘉泰姆

 Less than 1 mW at 5 V output nAZ嘉泰姆

 Fail safe operation nAZ嘉泰姆

 Adjacent pin-to-pin short-circuit fault nAZ嘉泰姆

 Open circuit pin faultnAZ嘉泰姆

   应用范围 返回TOPnAZ嘉泰姆

 Adaptors for smart phones, tablets, netbooks, digital cameras, and bluetooth accessories nAZ嘉泰姆

 Portable Battery Packs supporting QC.20 functions nAZ嘉泰姆

 Car Cargers supporting QC2.0 functions nAZ嘉泰姆

 Ogther USB power output ports supporting QC2.0 functionsnAZ嘉泰姆

   技术规格书（产品PDF) 返回TOP nAZ嘉泰姆

     需要详细的PDF规格书请扫一扫微信联系我们，还可以获得免费样品以及技术支持</span>！</span>
