DC-DC Boost Regulator CXSU63027 using the external NMOSFET. It is a high efficiency boost converter with 600mV feedback voltage. A switching frequency of 550KHz minimizes solution footprint by allowi

   产品概述 返回TOP7e0嘉泰姆

              The CXSU63027 using the external NMOSFET. It is a high efficiency boost converter with 600mV feedback voltage. A switching frequency of 550KHz minimizes solution footprint by allowing the use of tiny low profile inductors and ceramic capacitors. The current mode PWM/PFM design is internally compensated, and the device has a 1.6V startup voltage with 1mA load. It needs few external components, only inductance, resistance and capacitance can meet the driving capacity.

   产品特点 返回TOP7e0嘉泰姆

 Min1.6V Startup @1mA Load 7e0嘉泰姆

 600mV Feedback Voltage 7e0嘉泰姆

 550KHz Internal Oscillator 7e0嘉泰姆

 Soft Startup: 10mS Typical 7e0嘉泰姆

 Peak Current Programmable by Bottom Sensing Resistor 7e0嘉泰姆

 300μA Typical Iq 7e0嘉泰姆

 Internal PWM/PFM Auto Mode Switching 7e0嘉泰姆

 Up to 90% Efficiency 7e0嘉泰姆

 External Enable 7e0嘉泰姆

 Power OFF Current<1μA 7e0嘉泰姆

 Over Voltage Protection 7e0嘉泰姆

 140℃ Thermal Shut Down, 20℃ Hysteresis7e0嘉泰姆

   应用范围 返回TOP7e0嘉泰姆

   USB Charger7e0嘉泰姆

   技术规格书（产品PDF) 返回TOP 7e0嘉泰姆

     需要详细的PDF规格书请扫一扫微信联系我们，还可以获得免费样品以及技术支持</span>！</span>
