AC/DC LED照明恒流LED驱动Constant current LED driver CXLE86164 primary side control offline LED lighting controller which can achieve accurate LED current and low system cost for an isolated lighting applic

   产品概述 返回TOPJ8j嘉泰姆

     CXLE86164 is a primary side control offline LED lighting controller which can achieve accurate LED current and low system cost for an isolated lighting application in a single stage converter. It significantly simplifies the LED lighting system design by eliminating the secondary side feedback components and the opto-coupler. J8j嘉泰姆

The LED current can be adjusted externally by the sense resistor Rs at CS pin. The extremely low start up current and very low operation current (typical 350uA) reduce the power consumption thus lead to high efficiency and low standby power consumption.  J8j嘉泰姆

CXLE86164 offers comprehensive protection coverage with auto-recovery features including open loop protection, short circuit protection, cycle-by-cycle current limiting, VDD over voltage protection, built-in leading edge blanking, VDD under voltage lockout (UVLO), etc.  CXLE86164 is offered in SOT23-5 packageJ8j嘉泰姆

   产品特点 返回TOPJ8j嘉泰姆

J8j嘉泰姆

󰂄 High precision Constant Current Regulation at Universal AC input J8j嘉泰姆

󰂄 Primary-side Sensing and Regulation Without TL431 and Opto-coupler J8j嘉泰姆

󰂄 Low System Cost and High Efficiency 󰂄 Programmable CC Regulation J8j嘉泰姆

󰂄 Built-in Primary winding inductance compensation J8j嘉泰姆

󰂄 Drivability for BJT Switch J8j嘉泰姆

󰂄 Ultra Low Start-up Current (Typ. 1uA) 󰂄 Short Circuit Protection 󰂄 Open Loop Protection J8j嘉泰姆

󰂄 Cycle-by-Cycle Current Limiting J8j嘉泰姆

󰂄 Built-in Leading Edge Blanking (LEB) 󰂄 VDD Over Voltage Protection J8j嘉泰姆

󰂄 VDD Under Voltage Lockout with HysteresisJ8j嘉泰姆

   应用范围 返回TOPJ8j嘉泰姆

󰂄 LED lightingJ8j嘉泰姆

   技术规格书（产品PDF) 返回TOP J8j嘉泰姆

     需要详细的PDF规格书请扫一扫微信联系我们，还可以获得免费样品以及技术支持</span>！</span>
