Low Dropout Linear Regulator Controller CXLD64159 serise is a low dropout linear regulator controller,drive an external N-Channel MOSFET and provides an adjustable output by using an external resisti

   产品概述 返回TOPA5X嘉泰姆

The CXLD64159 serise is a low dropout linear regulator controller. The CXLD64159 serise could drive an external N-Channel MOSFET and provides an adjustable output by using an external resistive divider. The CXLD64159 serise integrates various functions. For example, a Power-On-Reset (POR) circuit monitors VCC supply voltage to prevent wrong operations; the function of Under-Voltage Protection (UVP) protects the device from short circuit condition. A POK indicates that the output status with time delay which is set internally. It can control other converter for power sequence. Moreover, the CXLD64159 serise can be enabled by other power system; namely, holding the EN above 1.6V enables output and pulling the EN under 0.4 disables output. The CXLD64159serise is available in a SOT-23-6 package.

   产品特点 返回TOPA5X嘉泰姆

· Wide Supply Voltage Range from 4.5 to 13.5V A5X嘉泰姆

· High Output AccuracyOver Operating Temperature and Loading Ranges A5X嘉泰姆

· Fast Transient Response A5X嘉泰姆

· Power-On-Reset Monitoring on VCC A5X嘉泰姆

· Internal Soft-Start Function A5X嘉泰姆

· Low Shutdown Current: < 5mA A5X嘉泰姆

· Enable Control Function A5X嘉泰姆

· Under-Voltage Protection A5X嘉泰姆

· Power-OK Output with a Delay Time A5X嘉泰姆

· Four Versions of IC Available: A5X嘉泰姆

- CXLD64159: VREF =0.8V, UVP Activated after VOUTis Ready A5X嘉泰姆

- CXLD64159A: VREF =0.8V, UVP Activated after VCCis Supplied A5X嘉泰姆

- CXLD64159B: VREF =0.5V, UVP Activated after VOUTis Ready A5X嘉泰姆

- CXLD64159C: VREF =0.5V, UVP Activated after VCCis Supplied A5X嘉泰姆

· SOT-23-6 Package A5X嘉泰姆

· Lead Free and Green Devices Available (RoHS Compliant)A5X嘉泰姆

   应用范围 返回TOPA5X嘉泰姆

· Note Book PC Applications A5X嘉泰姆

· Motherboard ApplicationsA5X嘉泰姆

   技术规格书（产品PDF) 返回TOP A5X嘉泰姆

     需要详细的PDF规格书请扫一扫微信联系我们，还可以获得免费样品以及技术支持</span>！</span>
