产品概述 返回TOPdyE嘉泰姆
The CXSD6287 uses fixed 200kHz switching frequency,
voltage mode, synchronous PWM controller which drives
dual N-channel MOSFETs. The device integrates the
control, monitoring and protection functions into a single
package, provides one controlled power output with
under-voltage protection.
The CXSD6287 provides excellent regulation for output
load variation. The internal 1.2V temperature-compensated
reference voltage is designed to meet the requirement
of low output voltage applications. An built-in digital softstart
with fixed soft-start interval prevents the output voltage
from overshoot as well as limiting the input current.
The CXSD6287 with excellent protection functions: POR
and UVP. The Power-On-Reset (POR) circuit can monitor
VCC supply voltage exceeds its threshold voltage while
the controller is running, and a built-in digital soft-start
provides output with controlled voltage rise. The UnderVoltage
Protection (UVP) monitors the voltage of FB pin
for short-circuit protection. When the VFB is less than
50% of VREF (0.6V), the controller will shutdown the IC
directly.
产品特点 返回TOPdyE嘉泰姆
· Single 12V Power Supply Required dyE嘉泰姆
· Fast Transient Response
- 0~90% Duty Ratio dyE嘉泰姆
· 1.2V Reference with 1% Accuracy dyE嘉泰姆
· Shutdown Function by Controlling COMP Pin
Voltage dyE嘉泰姆
· Internal Soft-Start (5.1ms) Function dyE嘉泰姆
· Voltage Mode PWM Control DesigndyE嘉泰姆
· Under-Voltage Protection dyE嘉泰姆
· 200kHz Fixed Switching Frequency dyE嘉泰姆
· SOP-8P Package dyE嘉泰姆
· Lead Free and Green Devices Available
(RoHS Compliant)dyE嘉泰姆
应用范围 返回TOPdyE嘉泰姆
· Graphics Card dyE嘉泰姆
· Mother Board dyE嘉泰姆
· SMPSdyE嘉泰姆
技术规格书（产品PDF) 返回TOP dyE嘉泰姆
需要详细的PDF规格书请扫一扫微信联系我们，还可以获得免费样品以及技术支持</span>！</span>
dyE嘉泰姆
dyE嘉泰姆
产品封装图 返回TOPdyE嘉泰姆
dyE嘉泰姆
dyE嘉泰姆
电路原理图 返回TOPdyE嘉泰姆
dyE嘉泰姆
dyE嘉泰姆
dyE嘉泰姆
Switching Regulator > Buck ControllerdyE嘉泰姆 |
Part_No dyE嘉泰姆 | Package dyE嘉泰姆 | Topology dyE嘉泰姆 | ArchidyE嘉泰姆 tectudyE嘉泰姆 | PhasedyE嘉泰姆 | No.ofdyE嘉泰姆 PWMdyE嘉泰姆 OutputdyE嘉泰姆 | Output dyE嘉泰姆 CurrentdyE嘉泰姆 (A) dyE嘉泰姆 | InputdyE嘉泰姆 Voltage (V) dyE嘉泰姆 | ReferencedyE嘉泰姆 VoltagedyE嘉泰姆 (V) dyE嘉泰姆 | Bias dyE嘉泰姆 VoltagedyE嘉泰姆 (V) dyE嘉泰姆 | QuiescentdyE嘉泰姆 CurrentdyE嘉泰姆 (uA) dyE嘉泰姆 |
mindyE嘉泰姆 | maxdyE嘉泰姆 |
CXSD6273dyE嘉泰姆 | SOP-14|QSOP-16dyE嘉泰姆 QFN4x4-16dyE嘉泰姆 | BuckdyE嘉泰姆 | VM dyE嘉泰姆 | 1 dyE嘉泰姆 | 1 dyE嘉泰姆 | 30dyE嘉泰姆 | 2.9 dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.9dyE嘉泰姆 | 12 dyE嘉泰姆 | 8000dyE嘉泰姆 |
CXSD6274dyE嘉泰姆 | SOP-8dyE嘉泰姆 | BuckdyE嘉泰姆 | VM dyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 20dyE嘉泰姆 | 2.9 dyE嘉泰姆 | 13.2 dyE嘉泰姆 | 0.8dyE嘉泰姆 | 12dyE嘉泰姆 | 5000dyE嘉泰姆 |
CXSD6274CdyE嘉泰姆 | SOP-8dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 20dyE嘉泰姆 | 2.9dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.8dyE嘉泰姆 | 12dyE嘉泰姆 | 5000dyE嘉泰姆 |
CXSD6275dyE嘉泰姆 | QFN4x4-24dyE嘉泰姆 | MultiphasedyE嘉泰姆 | VMdyE嘉泰姆 | 2dyE嘉泰姆 | 1dyE嘉泰姆 | 60dyE嘉泰姆 | 3.1dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.6dyE嘉泰姆 | 12dyE嘉泰姆 | 5000dyE嘉泰姆 |
CXSD6276dyE嘉泰姆 | SOP-8dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 20dyE嘉泰姆 | 2.2dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.8dyE嘉泰姆 | 5~12dyE嘉泰姆 | 2100dyE嘉泰姆 |
CXSD6276AdyE嘉泰姆 | SOP-8dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 20dyE嘉泰姆 | 2.2dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.8dyE嘉泰姆 | 5~12dyE嘉泰姆 | 2100dyE嘉泰姆 |
CXSD6277/A/BdyE嘉泰姆 | SOP8|TSSOP8dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 5dyE嘉泰姆 | 5dyE嘉泰姆 | 13.2dyE嘉泰姆 | 1.25|0.8dyE嘉泰姆 | 5~12dyE嘉泰姆 | 3000dyE嘉泰姆 |
CXSD6278dyE嘉泰姆 | SOP-8dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 10dyE嘉泰姆 | 3.3dyE嘉泰姆 | 5.5dyE嘉泰姆 | 0.8dyE嘉泰姆 | 5dyE嘉泰姆 | 2100dyE嘉泰姆 |
CXSD6279BdyE嘉泰姆 | SOP-14dyE嘉泰姆 | BuckdyE嘉泰姆 | VM dyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 10dyE嘉泰姆 | 5dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.8dyE嘉泰姆 | 12dyE嘉泰姆 | 2000dyE嘉泰姆 |
CXSD6280dyE嘉泰姆 | TSSOP-24dyE嘉泰姆 |QFN5x5-32dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 20dyE嘉泰姆 | 5dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.6dyE嘉泰姆 | 5~12dyE嘉泰姆 | 4000dyE嘉泰姆 |
CXSD6281NdyE嘉泰姆 | SOP14|QSOP16dyE嘉泰姆 |QFN-16dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 30dyE嘉泰姆 | 2.9dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.9dyE嘉泰姆 | 12dyE嘉泰姆 | 4000dyE嘉泰姆 |
CXSD6282dyE嘉泰姆 | SOP-14dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 30dyE嘉泰姆 | 2.2dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.6dyE嘉泰姆 | 12dyE嘉泰姆 | 5000dyE嘉泰姆 |
CXSD6282AdyE嘉泰姆 | SOP-14dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 30dyE嘉泰姆 | 2.2dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.6dyE嘉泰姆 | 12dyE嘉泰姆 | 5000dyE嘉泰姆 |
CXSD6283dyE嘉泰姆 | SOP-14dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 25dyE嘉泰姆 | 2.2dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.8dyE嘉泰姆 | 12dyE嘉泰姆 | 5000dyE嘉泰姆 |
CXSD6284/AdyE嘉泰姆 | LQFP7x7 48dyE嘉泰姆 |TQFN7x7-48dyE嘉泰姆 | Buck|BoostdyE嘉泰姆 |FlybackdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 6dyE嘉泰姆 | 0.015dyE嘉泰姆 | 1.4dyE嘉泰姆 | 6.5dyE嘉泰姆 | -dyE嘉泰姆 | 5dyE嘉泰姆 | 1800dyE嘉泰姆 |
CXSD6285dyE嘉泰姆 | TSSOP-24PdyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 20dyE嘉泰姆 | 2.97dyE嘉泰姆 | 5.5dyE嘉泰姆 | 0.8dyE嘉泰姆 | 5~12dyE嘉泰姆 | 5000dyE嘉泰姆 |
CXSD6286dyE嘉泰姆 | SOP-14dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 10dyE嘉泰姆 | 5dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.8dyE嘉泰姆 | 12dyE嘉泰姆 | 3000dyE嘉泰姆 |
CXSD6287dyE嘉泰姆 | SOP-8-P|DIP-8dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 30dyE嘉泰姆 | 2.9dyE嘉泰姆 | 13.2dyE嘉泰姆 | 1.2dyE嘉泰姆 | 12dyE嘉泰姆 | 3000dyE嘉泰姆 |
CXSD6288dyE嘉泰姆 | SSOP28dyE嘉泰姆 QFN4x4-24dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 20dyE嘉泰姆 | 5dyE嘉泰姆 | 24dyE嘉泰姆 | 0.9dyE嘉泰姆 | 5dyE嘉泰姆 | 1200dyE嘉泰姆 |
CXSD6289dyE嘉泰姆 | SOP-20dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 20dyE嘉泰姆 | 2.2dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.6dyE嘉泰姆 | 5~12dyE嘉泰姆 | 4000dyE嘉泰姆 |
CXSD6290dyE嘉泰姆 | SOP8|DFN3x3-10dyE嘉泰姆 |
| VMdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | -dyE嘉泰姆 | -dyE嘉泰姆 | -dyE嘉泰姆 | -dyE嘉泰姆 | 5~12dyE嘉泰姆 | 550dyE嘉泰姆 |
CXSD6291HCdyE嘉泰姆 | DIP8|SOP-8dyE嘉泰姆 | Buck|BoostdyE嘉泰姆 |FlybackdyE嘉泰姆 |ForwarddyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 1.2dyE嘉泰姆 | 9dyE嘉泰姆 | 24dyE嘉泰姆 | 5dyE嘉泰姆 | 9 ~ 24dyE嘉泰姆 |
CXSD6292dyE嘉泰姆 | SSOP16|QFN4x4-16dyE嘉泰姆 |TQFN3x3-16dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 25dyE嘉泰姆 | 3dyE嘉泰姆 | 25dyE嘉泰姆 | 0.6dyE嘉泰姆 | 5dyE嘉泰姆 | 1700dyE嘉泰姆 |
CXSD6293dyE嘉泰姆 | TDFN3x3-10dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 25dyE嘉泰姆 | 3dyE嘉泰姆 | 25dyE嘉泰姆 | 0.5dyE嘉泰姆 | 5dyE嘉泰姆 | 350dyE嘉泰姆 |
CXSD6294dyE嘉泰姆 | QFN4x4-24dyE嘉泰姆 | BuckdyE嘉泰姆 | CMdyE嘉泰姆 | 2dyE嘉泰姆 | 1dyE嘉泰姆 | 40dyE嘉泰姆 | 4.5dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.6dyE嘉泰姆 | 5~12dyE嘉泰姆 | 4000dyE嘉泰姆 |
CXSD6295dyE嘉泰姆 | SOP8P|TDFN3x3-10dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 20dyE嘉泰姆 | 3dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.8dyE嘉泰姆 | 5~12dyE嘉泰姆 | 2500dyE嘉泰姆 |
CXSD6296A|B|C|DdyE嘉泰姆 | SOP8PdyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 25dyE嘉泰姆 | 3dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.6|0.8dyE嘉泰姆 | 5~12dyE嘉泰姆 | 1200dyE嘉泰姆 |
CXSD6297dyE嘉泰姆 | TDFN3x3-10dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 25dyE嘉泰姆 | 4dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.8dyE嘉泰姆 | 5~12dyE嘉泰姆 | 2000dyE嘉泰姆 |
CXSD6298dyE嘉泰姆 | TDFN3x3-10dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 25dyE嘉泰姆 | 4.5dyE嘉泰姆 | 25dyE嘉泰姆 | 0.6dyE嘉泰姆 | 5~12dyE嘉泰姆 | 80dyE嘉泰姆 |
CXSD6299|AdyE嘉泰姆 | SOP-8PdyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 25dyE嘉泰姆 | 4.5dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.8dyE嘉泰姆 | 5~12dyE嘉泰姆 | 16000dyE嘉泰姆 |
CXSD62100dyE嘉泰姆 | TQFN3x3-10dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 25dyE嘉泰姆 | 4.5dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.6dyE嘉泰姆 | 5~12dyE嘉泰姆 | 2500dyE嘉泰姆 |
CXSD62101|LdyE嘉泰姆 | TDFN3x3-10dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 30dyE嘉泰姆 | 3dyE嘉泰姆 | 25dyE嘉泰姆 | 0.8dyE嘉泰姆 | 5~12dyE嘉泰姆 | 2000dyE嘉泰姆 |
CXSD62102dyE嘉泰姆 | TQFN3x3-16dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 30dyE嘉泰姆 | 1.8dyE嘉泰姆 | 28dyE嘉泰姆 | 0.6dyE嘉泰姆 | 5dyE嘉泰姆 | 600dyE嘉泰姆 |
CXSD62102AdyE嘉泰姆 | TQFN 3x3 16dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 30dyE嘉泰姆 | 1.8dyE嘉泰姆 | 28dyE嘉泰姆 | 0.6dyE嘉泰姆 | 5dyE嘉泰姆 | 600dyE嘉泰姆 |
CXSD62103dyE嘉泰姆 | QFN4x4-24dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 2dyE嘉泰姆 | 1dyE嘉泰姆 | 50dyE嘉泰姆 | 4.5dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.6dyE嘉泰姆 | 5~12dyE嘉泰姆 | 5000dyE嘉泰姆 |
CXSD62104dyE嘉泰姆 | TQFN4x4-24dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 15dyE嘉泰姆 | 6dyE嘉泰姆 | 25dyE嘉泰姆 | 2dyE嘉泰姆 | NdyE嘉泰姆 | 550dyE嘉泰姆 |
CXSD62105dyE嘉泰姆 | TQFN4x4-24dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 15dyE嘉泰姆 | 6dyE嘉泰姆 | 25dyE嘉泰姆 | 2dyE嘉泰姆 | NdyE嘉泰姆 | 550dyE嘉泰姆 |
CXSD62106|AdyE嘉泰姆 | TQFN4x4-4dyE嘉泰姆 TQFN3x3-20dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 20dyE嘉泰姆 | 3dyE嘉泰姆 | 28dyE嘉泰姆 | 0.75dyE嘉泰姆 | 5dyE嘉泰姆 | 800dyE嘉泰姆 |
CXSD62107dyE嘉泰姆 | TQFN3x3-16dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 20dyE嘉泰姆 | 1.8dyE嘉泰姆 | 28dyE嘉泰姆 | 0.75dyE嘉泰姆 | 5dyE嘉泰姆 | 400dyE嘉泰姆 |
CXSD62108dyE嘉泰姆 | QFN3.5x3.5-14dyE嘉泰姆 |TQFN3x3-16dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 20dyE嘉泰姆 | 1.8dyE嘉泰姆 | 28dyE嘉泰姆 | 0.75dyE嘉泰姆 | 5dyE嘉泰姆 | 400dyE嘉泰姆 |
CXSD62109dyE嘉泰姆 | TQFN3x3-16dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 20dyE嘉泰姆 | 1.8dyE嘉泰姆 | 28dyE嘉泰姆 | 0.75dyE嘉泰姆 | 5dyE嘉泰姆 | 400dyE嘉泰姆 |
CXSD62110dyE嘉泰姆 | QFN3x3-20dyE嘉泰姆 TQFN3x3-16dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 20dyE嘉泰姆 | 3dyE嘉泰姆 | 28dyE嘉泰姆 | 1.8|1.5|0.5dyE嘉泰姆 | 5dyE嘉泰姆 | 740dyE嘉泰姆 |
CXSD62111dyE嘉泰姆 | TQFN4x4-24dyE嘉泰姆 |QFN3x3-20dyE嘉泰姆 | BuckdyE嘉泰姆 | CMdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 15dyE嘉泰姆 | 5dyE嘉泰姆 | 28dyE嘉泰姆 | 0.5dyE嘉泰姆 | NdyE嘉泰姆 | 3000dyE嘉泰姆 |
CXSD62112dyE嘉泰姆 | TDFN3x3-10dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 20dyE嘉泰姆 | 1.8dyE嘉泰姆 | 28dyE嘉泰姆 | 0.5dyE嘉泰姆 | 5dyE嘉泰姆 | 250dyE嘉泰姆 |
CXSD62113|CdyE嘉泰姆 | TQFN3x3-20dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 15dyE嘉泰姆 | 6dyE嘉泰姆 | 25dyE嘉泰姆 | 2dyE嘉泰姆 | NdyE嘉泰姆 | 550dyE嘉泰姆 |
CXSD62113EdyE嘉泰姆 | TQFN 3x3 20dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 2dyE嘉泰姆 | 2dyE嘉泰姆 | 11dyE嘉泰姆 | 6dyE嘉泰姆 | 25dyE嘉泰姆 | 2dyE嘉泰姆 | NdyE嘉泰姆 | 550dyE嘉泰姆 |
CXSD62114dyE嘉泰姆 | TQFN3x3-20dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 2dyE嘉泰姆 | 2dyE嘉泰姆 | 11dyE嘉泰姆 | 5.5dyE嘉泰姆 | 25dyE嘉泰姆 | 2dyE嘉泰姆 | NdyE嘉泰姆 | 280dyE嘉泰姆 |
CXSD62115dyE嘉泰姆 | QFN4x4-24dyE嘉泰姆 | MultiphasedyE嘉泰姆 | VMdyE嘉泰姆 | 2dyE嘉泰姆 | 1dyE嘉泰姆 | 60dyE嘉泰姆 | 3.1dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.85dyE嘉泰姆 | 12dyE嘉泰姆 | 5000dyE嘉泰姆 |
CXSD62116A|B|CdyE嘉泰姆 | SOP-8PdyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 20dyE嘉泰姆 | 2.9dyE嘉泰姆 | 13.2dyE嘉泰姆 | 0.8dyE嘉泰姆 | 12dyE嘉泰姆 | 16000dyE嘉泰姆 |
CXSD62117dyE嘉泰姆 | SOP-20dyE嘉泰姆 | BuckdyE嘉泰姆 | VMdyE嘉泰姆 | 2dyE嘉泰姆 | 2dyE嘉泰姆 | 30dyE嘉泰姆 | 10dyE嘉泰姆 | 13.2dyE嘉泰姆 | 1dyE嘉泰姆 | 12dyE嘉泰姆 | 5000dyE嘉泰姆 |
CXSD62118dyE嘉泰姆 | TDFN3x3-10dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 1dyE嘉泰姆 | 25dyE嘉泰姆 | 1.8dyE嘉泰姆 | 28dyE嘉泰姆 | 0.7dyE嘉泰姆 | 5dyE嘉泰姆 | 250dyE嘉泰姆 |
CXSD62119dyE嘉泰姆 | TQFN3x3-20dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 2dyE嘉泰姆 | 1dyE嘉泰姆 | 40dyE嘉泰姆 | 1.8dyE嘉泰姆 | 25dyE嘉泰姆 | REFIN SettingdyE嘉泰姆 | 5dyE嘉泰姆 | 700dyE嘉泰姆 |
CXSD62120dyE嘉泰姆 | QFN 3x3 20dyE嘉泰姆 TQFN 3x3 16dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 20dyE嘉泰姆 | 3dyE嘉泰姆 | 28dyE嘉泰姆 | 1.8|1.5 1.35|1.2 0.5dyE嘉泰姆 | 5dyE嘉泰姆 | 800dyE嘉泰姆 |
CXSD62121AdyE嘉泰姆 | TQFN3x3 20dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 15dyE嘉泰姆 | 3dyE嘉泰姆 | 28dyE嘉泰姆 | 0.75dyE嘉泰姆 | 5dyE嘉泰姆 | 220dyE嘉泰姆 |
CXSD62121BdyE嘉泰姆 | TQFN3x3 20dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 15dyE嘉泰姆 | 3dyE嘉泰姆 | 28dyE嘉泰姆 | 0.75dyE嘉泰姆 | 5dyE嘉泰姆 | 220dyE嘉泰姆 |
CXSD62121dyE嘉泰姆 | TQFN3x3-20dyE嘉泰姆 | BuckdyE嘉泰姆 | COTdyE嘉泰姆 | 1dyE嘉泰姆 | 2dyE嘉泰姆 | 20dyE嘉泰姆 | 3dyE嘉泰姆 | 28dyE嘉泰姆 | 0.75dyE嘉泰姆 | 5dyE嘉泰姆 | 180dyE嘉泰姆 |
