CXSD62298高效同步双通道同步PWM降压DC/DC转换器Dual Channe l Synchro nous Buck DC/DC Converter high efficiency synchronous,dual channel working under an input voltage range of 2.5V to 5.5V

   产品概述 返回TOPvwU嘉泰姆

       CXSD62298是高效同步，双通道PWM降压直流/直流转换器。在2.5 v的输入电压范围</span>

下工作5.5 v。它集成了两种PWM同步降压直流-直流转换器。</span>

The CXSD62298 is a high efficiency synchronous,dual channel PWM step-down

DC/DC converter working under an input voltage range of 2.5V to 5.5V. It integrates

 two PWM synchronous step-down DC-DC converters. 100% duty cycle capability

extends battery life in portable devices,while the quiescent current (one channel) is

200μA with no load, and drops to<1μA in shutdown.Each DC-DC converter has

independent enable input and short-circuit protection allowing versatile power

sequence combination.The CXSD62298 converters are available in the  industry

standard DFN3*3-10L packages (or upon request).

   产品特点 返回TOPvwU嘉泰姆

vwU嘉泰姆

 Up to 94% EfficiencyvwU嘉泰姆

 Current Mode Operation for Excellent Line and Load Transient ResponsevwU嘉泰姆

 Output Voltage: 0.6V ～ 5.5VvwU嘉泰姆

 Low Quiescent Current (one Channel):200μAvwU嘉泰姆

 Up to 800mA Load Current vwU嘉泰姆

 Soft-startvwU嘉泰姆

 Automatic PWM/PFM Mode SwitchingvwU嘉泰姆

 No Schottky Diode RequiredvwU嘉泰姆

 1MHz Constant Frequency OperationvwU嘉泰姆

 Short-Circuit ProtectionvwU嘉泰姆

 Shutdown Quiescent Current: < 1μAvwU嘉泰姆

 DFN3*3-10L PackagevwU嘉泰姆

   应用范围 返回TOPvwU嘉泰姆

vwU嘉泰姆

 Digital cameras and MP3vwU嘉泰姆

 Palmtop computers / PDAsvwU嘉泰姆

 Cellular phonesvwU嘉泰姆

 Wireless handsets and DSL modemsvwU嘉泰姆

 Portable media playersvwU嘉泰姆

 PC cardsvwU嘉泰姆

   技术规格书（产品PDF) 返回TOP vwU嘉泰姆

     需要详细的PDF规格书请扫一扫微信联系我们，还可以获得免费样品以及技术支持</span>！</span>
