CXSD62303 800mA,2-6V Input,1.5MHz Synchronous Step-Down Converter constant frequency, current mode PWM step-down converter. The device integrates a main switch and a synchronous rectifier

   产品概述 返回TOPoC5嘉泰姆

  The CXSD62303 is a constant frequency, current mode PWM step-down

converter. The device integrates a main switch and a synchronous rectifier

 for high efficiency without an external Schottky diode. It is ideal for

powering portable equipment that runs from a single cell Lithium-Ion (Li+)

battery. The output voltage can be regulated as low as 0.6V. The CXSD62303

can also run at 100% duty cycle for low dropout operation, extending battery

 life in portable system. This device offers two operation modes, PWM control

and PFM Mode switching control, which allows a high efficiency over the

wider range of the load.The CXSD62303 is offered in a low profile 5-pin,SOT

package, and is available in an adjustable version and fixed output voltage

 of 1.2V,1.5V, 1.8V,2.5V and 3.3V.

   产品特点 返回TOPoC5嘉泰姆

oC5嘉泰姆

High Efficiency: Up to 96%oC5嘉泰姆

1.5MHz Constant Frequency OperationoC5嘉泰姆

800mA Output CurrentoC5嘉泰姆

No Schottky Diode RequiredoC5嘉泰姆

2V to 6V Input Voltage RangeoC5嘉泰姆

Output Voltage as Low as 0.6VoC5嘉泰姆

PFM Mode for High Efficiency in Light LoadoC5嘉泰姆

100% Duty Cycle in Dropout OperationoC5嘉泰姆

Low Quiescent Current: 20μAoC5嘉泰姆

Slope Compensated Current Mode Control foroC5嘉泰姆

Excellent Line and Load Transient ResponseoC5嘉泰姆

Short Circuit ProtectionoC5嘉泰姆

Thermal Fault ProtectionoC5嘉泰姆

Inrush Current Limit and Soft StartoC5嘉泰姆

<1μA Shutdown CurrentoC5嘉泰姆

SOT23-5 packageoC5嘉泰姆

   应用范围 返回TOPoC5嘉泰姆

oC5嘉泰姆

Cellular and Smart PhonesoC5嘉泰姆

Wireless and DSL ModemsoC5嘉泰姆

PDAsoC5嘉泰姆

Portable InstrumentsoC5嘉泰姆

Digital Still and Video CamerasoC5嘉泰姆

MP3 PlayersoC5嘉泰姆

   技术规格书（产品PDF) 返回TOP oC5嘉泰姆

     需要详细的PDF规格书请扫一扫微信联系我们，还可以获得免费样品以及技术支持</span>！</span>
