一,产品概述(General Description)
The JTM4447 uses advanced trench technology to provide
excellent RDS(ON), This device is suitable for use as a load
switch or power management.

二.产品特点(Features)
1.VDS = -30V,ID = -25A   RDS(ON) <9mΩ @ VGS=-10V
2.High power and current handing capability
3. Lead free product is acquired
4. Surface mount package

三,应用范围 (Applications)
1.Power management
2.Load switch

四,产品封装图 (Package)

五,电路原理图

六, 产品PCB
(略)
七.产品BOM
(略)
八.产品PDF文档

JTM4447

九,功能概述

Parameter	Symbol	Limit	Unit
Drain-Source Voltage	VDS	-30	V
Gate-Source Voltage	VGS	±20	V
Drain Current-Continuous	ID	-25	A
(Note 1) Drain Current-Pulsed	IDM	-70	A
Maximum Power Dissipation	PD	3.5	W
Operating Junction and Storage Temperature Range	TJ,TSTG	-55 To 150	℃
